V-CELL FG GT FILTER

AirPurete™ V-Cell FG GT Filter is engineered to provide superior filtration performance in gas turbine applications. Designed for use in demanding environments, this filter protects critical turbine components by effectively removing fine particles, contaminants, and corrosive agents from the air intake. Its advanced design enhances the efficiency and longevity of gas turbines, making it an essential component in industries where reliability and performance are paramount.

Product Features

Engineered to maintain high airflow with minimal resistance, reducing energy consumption.
High-strength glass-fiber media and polyurethane potting provide high burst resistance and leak-free performance.
Manufactured using an ABS plastic frame reinforced with plastic mesh on the downstream side.
Lightweight and easy to install with maximum dust-holding capacity.
Water and oil resistant, with vertical pleat orientation for superior drainage.

Applications

Gas Turbines

Oil & Gas

Power Generation

Industrial Manufacturing

Petrochemical Plants

Refining Industries

Specifications

Model	V Cell FG GT Filters
Type	V Bank – Rigid Pocket (4V)
Filter Grades (EN 779)	M5, F7, F8, F9
Filter Grades (ASHRAE 52.2) - MERV	11, 13, 14, 15, 16
Media	Fiber Glass
Media Separator	Hot Melt Beads
Frame	ABS Plastic (20mm Header)
Faceguard	All plastic mesh support (downstream side)
Maximum Temperature	80°C / 176°F
Burst Strength	35” WG
