RIGID BOX FILTER

AirPurete™ Rigid Box Filters are rigid, extended-surface air filters engineered to provide medium-to-high efficiency filtration and longer life cycles. Because of its rugged metal frame construction, the Rigid Box Filter is capable of operating in a wide variety of variable-air-volume (VAV) applications where fluctuations in airflow might render a non-rigid filter ineffective. These filters are composed of 100% synthetic fibers and are available in several ASHRAE efficiency ranges (MERV 12-15) to meet the unique demands of any environment.

Product Features

This design ensures a low pressure drop across the system, allowing for more efficient airflow.
High efficiency of the unit leads to significantly reduced energy costs over time.
Features durable plastic internal supports that maintain structural integrity under stress.
The deep pleated media pack is encased in metal frame and all the four edges of media are bonded to the frame to ensure a leak free operation.
Rigid box filters are lightweight and easy to install, reducing labor time and maintenance.
Available in a wide range of standard sizes to accommodate various HVAC configurations.
The rigid construction makes these filters ideal for use in variable air volume (VAV) systems where airflow rates fluctuate.

Applications

Air intake systems in combustion engines

Diesel generators

Gas Turbines

Electronic Manufacturing

Food Processing

Industrial Applications

Pharmaceutical

Spray painting plants

Specifications

Model	Rigid Box Filters
Type	Extended Surface Rigid Pocket Filter
Filter Grades (EN 779)	M6 / F6, F7, F8, F9
Filter Grades (ASHRAE 52.2) - MERV	12, 13, 14, 15
Media	Synthetic
Frame	GI / SS / Aluminum
Media Support	Expanded Metal Mesh
Recommended Final Pressure Drop	1.50” WG
Maximum Temperature	80°C
