PLAIN PANEL FILTER

AirPurete™ Plain Panel filters are cleanable and washable panel filters constructed from non-woven, high-loft synthetic polyester media. They are designed for coarse filtration in air intake systems for general ventilation and air handling units (AHUs) installed in public buildings, offices, factories, and various equipment types.

Product Features

Made of progressively built-up, thermally bonded synthetic polyester, the media’s multi-layer manufacturing technique ensures maximum dust loading with optimal low-pressure drop performance.
Ideal as a pre-filter to extend the lifespan of downstream fine filters, as a primary filter, or as a paint mist arrestor in spray booth exhaust systems.
Suitable for high-air-volume applications, high-humidity conditions, and corrosive environments.
The media is non-fiber-shedding and incinerable.
Filters can be cleaned using low-pressure compressed air or hosed with water from the clean-air side.
Their lightweight, sturdy, and compact design makes them easy to handle and ship.
Custom sizes are available in various face dimensions and depths up to 6”.

Applications

Air-Conditioning Systems

Car Ventilation

General Air Handling Unit

Intake, Exhaust Air Systems

Pharmaceutical

Bio Medical

Food Processing

Hospitals

Laboratories

Universities

Bio Technology

Gas Turbines

House Hold Applications

Paint Booths

Ventilation Systems

Specifications

Model	Plain Panel Filters
Type	Cleanable Pre-Filter / Washable Type
Filter Grades (EN 779)	G2 / G3 / G4
Filter Grades (ASHRAE 52.2) - MERV	4 / 6 / 8
Media	100% Synthetic-based polyester fiber
Media Support	PVC Coated steel mesh support on both sides
Frame	GI / SS / Aluminum
Recommended Final Pressure Drop	1.00" WG
Maximum Temperature	80°C
Flammability	UL 900 Classified
